EN5339QI
RoHS
/
Package QFN EP
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 0.6-4.6V 14W
PDF
/
Buying Options
Total Price: USD $5.68
Unit Price: USD $5.68115
≥1 USD $5.68115
≥10 USD $5.35957
≥100 USD $5.0562
≥500 USD $4.77
≥1000 USD $4.5
≥3000 USD $4.24528
Inventory: 1005
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 4.064mm
Length 6.096mm
Height 1.016mm
Technical
Switcher Configuration BUCK
Control Technique PULSE WIDTH MODULATION
Max Input Voltage 5.5V
Frequency - Switching 3.5MHz
Control Mode VOLTAGE-MODE
Min Input Voltage 2.4V
Voltage - Output 600mV
Current - Output 3A
Power Dissipation-Max 14W
Analog IC - Other Type SWITCHING REGULATOR
Temperature Grade INDUSTRIAL
Input Voltage-Nom 5V
Voltage - Output 1 4.6V
Max Output Current 3A
Output Type Adjustable
Efficiency 95 %
Number of Outputs 1
Pin Count 24
Time@Peak Reflow Temperature-Max (s) 10
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Technology CMOS
Subcategory Switching Regulator or Controllers
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 3
Part Status Active
Pbfree Code yes
Feature OCP, OTP, SCP, UVLO
JESD-609 Code e3
Published 2015
Packaging Tape and Reel
Physical
Number of Pins 24
Package / Case QFN EP
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
