B82801A0135A125

EPCOS
RoHS
/
Package /
Category Transformers / Current Sense Transformers
Description 4 WOUND PRIMARY Surface Mount TAPE & REEL Current Sense Transformer 5A 1.28mH 1MHz 4.1mm
PDF
/
Inventory: 2664
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC No SVHC

Dimensions

Width 3.5mm
Length 4.7mm

Technical

Primary Current 5A
Primary Type WOUND PRIMARY
Current - Input 5A
Voltage - Test 360V
Turns Ratio - Primary:Secondary 1:125
Transformer Type CURRENT SENSE TRANSFORMER
DC Resistance (DCR) - Parallel 13Ohm
Frequency (Max) 1MHz
Inductance 1.28 mH
Frequency 1MHz
Depth 4.1mm
Packing Method TAPE & REEL
Min Operating Temperature -40°C
Max Operating Temperature 125°C
ECCN Code EAR99
Pbfree Code yes

Physical

Weight 150mg
Number of Pins 4
Mount Surface Mount
