66331-8
RoHS
RoHS compliant
RoHS compliantPackage 062
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
CONN SKT .062 20-24AWG AU CRIMP
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9416
≥1 USD $0.9416
≥10 USD $0.87912
≥100 USD $0.84656
≥500 USD $0.838464
≥1000 USD $0.756624
≥3000 USD $0.73209
Inventory: 1890
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Plating Thickness 760 nm
Contact Finish Thickness 30.0μin 0.76μm
Height 3.05mm
Technical
Used With CPC, G SERIES AND M SERIES CONNECTOR
Cable Entry-Min 0.08 inch
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 2.54 mm
Test Current 13A
Contact Termination Crimp
Circuit Application Signal
Wire/Cable Gauge 20 AWG
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 24 AWG
Wire/Cable Type Discrete
Max Current Rating 13A
Wire Gauge 20-24 AWG
Operating Temperature (Min) -55°C
Contact Gender Female
Operating Temperature (Max) 90°C
Contact Finish Gold
Current Rating 13A
Depth 3.68mm
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Type Stamped
ECCN Code EAR99
Number of Terminations 1
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Multimate III+
Published 1998
Packaging Cut Tape (CT)
Physical
Underplate Material Nickel
Package / Case 062
Mount Cable
Contact Plating Gold, Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 4 Weeks
