ELF-18D215
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
COMMON MODE CHOKE 15MH 2LN TH
PDF
/
Inventory: 6116
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -20°C~105°C
Packaging Bulk
Published 2002
Series H
Size / Dimension 0.787Lx0.827W 20.00mmx21.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 105°C
Min Operating Temperature -20°C
Voltage - Rated AC 250V
Inductance 15 mH
Current 500mA
Number of Lines 2
DC Resistance (DCR) (Max) 1.091Ohm Typ
Inductance @ Frequency 15mH @ 1kHz
Dimensions
Height 19.9898mm
Length 19.9898mm
Width 21.0058mm
Height (Max) 0.787 20.00mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
