PLT10HH450180PNL
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pad
Category Filters / Common Mode Chokes
Description
CMC 18A 2LN 45 OHM SMD AEC-Q200
PDF
/
Buying Options
Total Price: USD $3.56
Unit Price: USD $3.55686
≥1 USD $3.55686
≥10 USD $3.129095
≥100 USD $2.874006
Inventory: 11
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Vertical, 4 PC Pad
Technical
Operating Temperature -55°C~125°C
Packaging Cut Tape (CT)
Series PLT10H
Size / Dimension 0.508Lx0.358W 12.90mmx9.10mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Additional Feature IMPEDANCE AT 10 MHZ
HTS Code 8504.50.80.00
Voltage - Rated DC 300V
Packing Method TR, EMBOSSED, 7 INCH
Number of Functions 2
Inductance 800 nH
Impedance 45Ohm
Max DC Current 18A
Filter Type Power Line
Number of Lines 2
DC Resistance (DCR) (Max) 1.8mOhm
Impedance @ Frequency 45Ohm @ 10MHz
Insulation Resistance-Min 10MOhm
Dimensions
Height 9.398mm
Width 6.6mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
