DLP11SA900HL2L
RoHS
RoHS compliant
RoHS compliantPackage 0504 (1210 Metric), 4 Lead
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 90Ohm 100MHz 150mA 1.4Ohm DCR SMD T/R
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.208558
≥1 USD $0.208558
≥10 USD $0.168804
≥100 USD $0.151759
≥500 USD $0.07885
≥1000 USD $0.07695
Inventory: 344
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height 820μm
Technical
Rated Voltage 5V
Impedance @ Frequency 90Ohm @ 100MHz
DC Resistance (DCR) (Max) 1.75Ohm
Number of Lines 2
DC Current 150mA
Filter Type Signal Line
Max DC Current 150mA
Current 150mA
Impedance 90Ohm
Test Frequency 100MHz
Case Code (Imperial) 0504
Case Code (Metric) 1210
Military Standard Not
Current Rating 150mA
Depth 1.1mm
Number of Functions 2
Packing Method TAPE AND REEL
Voltage - Rated DC 5V
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Resistance 90Ohm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 20%
Size / Dimension 0.049Lx0.039W 1.25mmx1.00mm
Series DLP11
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case 0504 (1210 Metric), 4 Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 6 Weeks
