B82732F2901B1
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
CMC 27MH 900MA 2LN TH
PDF
/
Inventory: 6103
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Weight 10.000011g
Material - Core Ferrite
Technical
Tolerance 50%
Termination Radial
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Voltage - Rated 250V
Shielding Unshielded
Depth 14.5mm
Current Rating 900mA
Voltage - Rated AC 250V
Approval Agency ENEC, UR, VDE
Inductance 27 mH
Test Frequency 10kHz
Impedance 300kOhm
Max DC Current 900mA
Lead/Base Style Pin
DC Resistance (DCR) - Parallel 770mOhm
Number of Lines 2
Current Rating (Max) 900mA
Dimensions
Height 13.5mm
Length 24.5mm
Width 14.5034mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
