SRF1006-102Y
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 1mH 1.4kOhm 100kHz 520mA 180mOhm DCR SMD T/R
PDF
/
Buying Options
Total Price: USD $1.18
Unit Price: USD $1.182057
≥1 USD $1.182057
≥10 USD $1.115149
≥100 USD $1.05203
≥500 USD $0.992479
≥1000 USD $0.936301
Inventory: 1182
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 8.7mm
Length 10mm
Height 6.5024mm
Technical
Inductance @ Frequency 1mH @ 100kHz
Rated Voltage 50V
Impedance @ Frequency 1.4kOhm @ 1MHz
DC Resistance (DCR) (Max) 180mOhm
Number of Lines 2
DC Current 520mA
Filter Type Signal Line
Current 520mA
Impedance 1.4kOhm
Test Frequency 100kHz
Inductance 1 mH
Depth 9mm
Number of Functions 2
Packing Method TAPE AND REEL
Voltage - Rated DC 50V
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.394Lx0.343W 10.00mmx8.70mm
Series SRF1006
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature -40°C~105°C
Physical
Package / Case Horizontal, 4 PC Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
