DS1305EN
RoHS
/
Package 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description
HH:MM:SS (12/24hr) Obsolete Clock/Calendar Surface Mount Real Time Clock (RTC) IC 96B -40C~85C 25.3muA~81muA @ 2V~5V 2V~5.5V
PDF
/
Buying Options
Total Price: USD $1.58
Unit Price: USD $1.5846
≥1 USD $1.5846
≥10 USD $1.30055
≥100 USD $1.2597
≥500 USD $1.21885
≥1000 USD $1.178
Inventory: 87759
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Voltage - Supply, Battery 2V~5.5V
Current - Timekeeping (Max) 25.3μA~81μA @ 2V~5V
Date Format YY-MM-DD-dd
Time Format HH:MM:SS (12/24 hr)
Memory Size 96B
Interface SPI
Voltage - Supply 2V~5.5V
Type Clock/Calendar
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Alarm, Leap Year, NVSRAM, Trickle-Charger
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Supplier Device Package 20-TSSOP
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
