DS1743WP-120
RoHS
/
Package 34-PowerCap? Module
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description
DUAL HH:MM:SS (24hr) CMOS Obsolete Real Time Clock (RTC) IC 2007 SECONDS 8KB 0C~70C
PDF
/
Inventory: 921
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 34-PowerCap? Module
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2007
JESD-609 Code e0
Feature Leap Year, NVSRAM, Y2K
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 34
ECCN Code EAR99
Type Clock/Calendar
Terminal Finish TIN LEAD
Additional Feature A POWERCAP MODULE CONTAINING CRYSTAL AND BATTERY REQUIRED
HTS Code 8473.30.11.80
Subcategory Timer or RTC
Technology CMOS
Voltage - Supply 2.97V~3.63V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 240
Supply Voltage 3.3V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DS1743
Pin Count 34
JESD-30 Code R-XDMA-U34
Qualification Status Not Qualified
Power Supplies 3.3V
Interface Parallel
Memory Size 8KB
Clock Frequency 0.032MHz
External Data Bus Width 8
Time Format HH:MM:SS (24 hr)
Date Format YY-MM-DD-dd
Current - Timekeeping (Max) 2mA @ 3.3V
Time-Min SECONDS
Interrupt Capability N
Voltage - Supply, Battery 3V
Volatile NO
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
