DS1337C
RoHS
/
Package 16-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description
DUAL HH:MM:SS (12/24hr) CMOS I2C Real Time Clock (RTC) IC 2006 -40C~85C 0.032MHz 10.3mm
PDF
/
Buying Options
Total Price: USD $5.88
Unit Price: USD $5.877084
≥1 USD $5.877084
≥10 USD $5.544418
≥100 USD $5.230584
≥500 USD $4.934511
≥1000 USD $4.6552
Inventory: 1278
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295, 7.50mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2006
JESD-609 Code e0
Feature Alarm, Leap Year, Square Wave Output
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type Clock/Calendar
Terminal Finish TIN LEAD
HTS Code 8542.39.00.01
Technology CMOS
Voltage - Supply 1.8V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 240
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 20
Base Part Number DS1337
Pin Count 16
JESD-30 Code R-PDSO-G16
Qualification Status Not Qualified
Interface I2C, 2-Wire Serial
Clock Frequency 0.032MHz
Number of Timers 1
Time Format HH:MM:SS (12/24 hr)
Date Format YY-MM-DD-dd
Current - Timekeeping (Max) 0.6μA @ 1.3V~1.8V
Information Access Method I2C
Dimensions
Height Seated (Max) 2.65mm
Length 10.3mm
Width 7.5mm
Compliance
RoHS Status Non-RoHS Compliant
