LTC6946IUFD-3
RoHS
/
Package 28-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description
Clock Clock/Frequency Synthesizer (RF/IF) Integer N 28-WFQFN Exposed Pad LTC6946 clock generator circuit 3.45V 5.79GHz 5mm -40C~105C
PDF
/
Buying Options
Total Price: USD $53.7
Unit Price: USD $53.6959
≥1 USD $53.6959
≥10 USD $44.05815
≥100 USD $42.6816
≥500 USD $41.30505
≥1000 USD $39.92755
Inventory: 1369
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 4mm
Length 5mm
Height Seated (Max) 0.8mm
Technical
Differential - Input:Output Yes/Yes
PLL Yes
Ratio - Input:Output 1:1
Input Clock
Frequency (Max) 5.79GHz
Number of Circuits 1
Power Supplies 3.35V
Supply Voltage-Max (Vsup) 3.45V
Qualification Status Not Qualified
JESD-30 Code R-PQCC-N28
Pin Count 28
Base Part Number LTC6946
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position QUAD
Voltage - Supply 3.15V~5.25V
Technology CMOS
Subcategory PLL or Frequency Synthesis Circuits
Additional Feature ALSO OPERATES IN SUPPLY VOLTAGE 4 TO 5.25V
Terminal Finish Matte Tin (Sn)
Type Clock/Frequency Synthesizer (RF/IF), Integer N
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature -40°C~105°C
