LMH2191TMX/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 8-WFBGA, DSBGA
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
BOTTOM Not Qualified Surface Mount Fanout Buffer (Distribution) Clock Fanout Buffer (Distribution) IC 33pF -40C~85C 52MHz 0.002A
PDF
/
Buying Options
Total Price: USD $1.67
Unit Price: USD $1.67105
≥1 USD $1.67105
≥10 USD $1.3718
≥100 USD $1.32905
≥500 USD $1.28535
≥1000 USD $1.2426
Inventory: 1360
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-WFBGA, DSBGA
Number of Pins 8
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type Fanout Buffer (Distribution)
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Packing Method TR
Voltage - Supply 2.5V~5.5V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number LMH2191
Pin Count 8
Number of Outputs 4
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.5V
Supply Voltage-Min (Vsup) 2.5V
Number of Circuits 1
Load Capacitance 33pF
Frequency (Max) 52MHz
Input Clock
Ratio - Input:Output 1:2
Max I(ol) 0.002 A
Differential - Input:Output No/No
fmax-Min 52 MHz
Dimensions
Height 675μm
Length 0m
Width 0m
Thickness 420μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
