MC10H646FNR2
RoHS
/
Package 28-LCC (J-Lead)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
PECL TTL 28-LCC (J-Lead) S-PQCC-J28 Obsolete clock buffer 4.57mm 5V 0.5ns 80MHz
PDF
/
Buying Options
Total Price: USD $4.84
Unit Price: USD $4.8412
≥1 USD $4.8412
≥10 USD $3.9729
≥100 USD $3.84845
≥500 USD $3.724
≥1000 USD $3.6005
Inventory: 1196
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 28-LCC (J-Lead)
Surface Mount YES
Technical
Operating Temperature 0°C~85°C
Packaging Tape & Reel (TR)
JESD-609 Code e0
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 28
Type Fanout Buffer (Distribution)
Terminal Finish TIN LEAD
Technology ECL
Voltage - Supply 4.75V~5.25V
Terminal Position QUAD
Terminal Form J BEND
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Output TTL
Pin Count 28
JESD-30 Code S-PQCC-J28
Qualification Status COMMERCIAL
Supply Voltage-Max (Vsup) 5.25V
Supply Voltage-Min (Vsup) 4.75V
Number of Circuits 1
Frequency (Max) 80MHz
Family 10H
Input PECL, TTL
Ratio - Input:Output 2:8
Differential - Input:Output Yes/No
Propagation Delay (tpd) 6.4 ns
Same Edge Skew-Max (tskwd) 0.5 ns
Dimensions
Height Seated (Max) 4.57mm
Compliance
RoHS Status Non-RoHS Compliant
