PI6C20800VE
RoHS
RoHS compliant
RoHS compliantPackage 48-BSSOP (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Application Specific
Description
48-BSSOP (0.295 7.50mm Width) PCI Express (PCIe) PI6C20800 PLL BASED CLOCK DRIVER application specific IC 7.49mm 250mA 3.3V 400MHz
PDF
/
Buying Options
Total Price: USD $3.22
Unit Price: USD $3.2224
≥1 USD $3.2224
≥10 USD $2.64385
≥100 USD $2.5612
≥500 USD $2.47855
≥1000 USD $2.3959
Inventory: 1554
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7.49mm
Height Seated (Max) 2.79mm
Technical
Number of True Outputs 8
Same Edge Skew-Max (tskwd) 0.05 ns
Main Purpose PCI Express (PCIe)
Differential - Input:Output Yes/Yes
PLL Yes
Logic IC Type PLL BASED CLOCK DRIVER
Ratio - Input:Output 1:8
Input HCSL
Output Characteristics 3-STATE
Family 6C
Frequency (Max) 400MHz
Nominal Supply Current 250mA
Number of Circuits 1
Supply Voltage-Max (Vsup) 3.465V
Operating Supply Voltage 3.3V
Base Part Number PI6C20800
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.635mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3.135V~3.465V
Subcategory Clock Drivers
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2012
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Number of Pins 48
Package / Case 48-BSSOP (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 4 Weeks
