PSA.1S.302.CLLC57
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 2P PNL MT SOLDER REC FEM 5.7mm CBL COLLET
PDF
/
Inventory: 6802
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass, Bronze
Mount Bulkhead, Free Hanging, Panel, Rear Side Nut
Mounting Type Free Hanging (In-Line); Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Backshell Material, Plating Brass, Chrome
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 1S
Feature Backshell
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets and Male Pins
Number of Positions 2
Color Silver
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation Keyed
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 15A
Shell Finish Chrome
Shell Size - Insert 302
Cable Opening 0.205 ~ 0.224 (5.20mm ~ 5.70mm)
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
