PHG.2B.308.CLLD52
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 8P SOLDER SCKT RECPT CABLE COLLET 5.2MM
PDF
/
Buying Options
Total Price: USD $41.69
Unit Price: USD $41.6944
≥1 USD $41.6944
Inventory: 17
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 46mm
Diameter 16.5mm
Technical
Cable Opening 0.165 ~ 0.205 (4.20mm ~ 5.20mm)
Contact Style Socket
Contact Gender Female
Shell Size - Insert 308
Shell Finish Chrome
Current Rating 10A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Fastening Type Push-Pull
Color Silver
Number of Positions 8
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Part Status Active
Pbfree Code yes
Feature Backshell
Series 2B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Copper, Gold, Nickel
Contact Material Bronze
