PHG.0B.307.CLLD42Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 7P SOLDER SCKT RECPT CABLE COLLET 4.2MM
PDF
/
Inventory: 4384
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Backshell Material, Plating Brass, Chrome
Technical
Operating Temperature -55°C~250°C
Packaging Bulk
Series 0B
Feature Backshell
Pbfree Code yes
Part Status Active
Termination Solder Cup
ECCN Code EAR99
Connector Type Receptacle, Female Sockets
Number of Positions 7
Color Silver
HTS Code 8536.69.40.20
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation G
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 2.5A
Shell Finish Chrome
Shell Size - Insert 307
Contact Gender Female
Contact Style Socket
Cable Opening 0.126 ~ 0.165 (3.20mm ~ 4.20mm)
Dimensions
Diameter 9.5mm
Length 34.5mm
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
