ENY.2B.302.PLLB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors FIXED RECEPTACLE W. EARTHING TAG
PDF
/
Inventory: 5176
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Mount Bulkhead, Panel, Rear Side Nut
Mounting Type Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Shell Material Polysulfone (PSU)
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -50°C~150°C
Packaging Bulk
Series 2B
Feature Ground
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Cup
Connector Type Receptacle, Female Sockets
Number of Positions 2
Color White
Fastening Type Push-Pull
Contact Finish - Mating Gold
Orientation Y
Shielding Shielded
Ingress Protection IP50 - Dust Protected
Current Rating 25A
Shell Size - Insert 302
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings IP50
