EGJ.3B.304.CYC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Connector
PDF
/
Inventory: 6741
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 39.4μin 1.00μm
Length 30.7mm
Diameter 25mm
Technical
Contact Style Pin
Shell Size - Insert 304
Shell Finish Chrome
Current Rating 19A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation J
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Male
Color Silver
Number of Positions 4
Connector Type Receptacle, Male Pins
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 3B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Bulkhead - Rear Side Nut
Mounting Type Panel Mount
Mount Bulkhead, Panel, Rear Side Nut
Contact Material NOT SPECIFIED
