EEG.1K.307.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors RECPT W.NUT(CdG) 7CTS
PDF
/
Inventory: 7136
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Contact Finish - Mating Gold
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Total Number of Contacts 7
Orientation G
Shielding Shielded
Ingress Protection IP66/68 - Dust Tight, Water Resistant, Waterproof
Current Rating 7A
Shell Finish Chrome
Shell Size - Insert 307
Voltage - Rated AC 950V
Contact Gender Female
Empty Shell NO
Backshell Type SOLID
Environmental Characteristics CORROSION/ENVIRONMENT/MOISTURE RESISTANT
Coupling Type SNAP
Wire/Cable Gauge 22 AWG
Voltage - Rated DC 1.34kV
Fastening Type Push-Pull
Color Silver
Number of Positions 7
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series 1K
Packaging Bulk
Operating Temperature -55°C~200°C
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP66, IP68, Water Resistant, Waterproof
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Bulkhead - Front Side Nut
Mounting Type Panel Mount
Mount Flanges, Front Side Nut, Panel
Contact Plating Copper, Gold, Nickel
Contact Material Bronze
