ECG.1B.305.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 5 PIN W.REMOVABLE BEZEL
PDF
/
Buying Options
Total Price: USD $22.71
Unit Price: USD $22.7128
≥1 USD $22.7128
≥10 USD $21.61456
Inventory: 164
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 19.8mm
Diameter 15.8mm
Technical
Coupling Type SNAP
Contact Style Socket
Backshell Type SOLID
Empty Shell NO
Contact Gender Female
Shell Size - Insert 305
Shell Finish Chrome
Current Rating 9A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Total Number of Contacts 5
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating Gold
Fastening Type Push-Pull
Color Silver
Number of Positions 5
Connector Type Receptacle, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series 1B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Feature Front and Rear Side Nut
Mounting Type Panel Mount
Mount Front, Panel, Rear Side Nut
Contact Material Bronze
