CA3100E36-7SBF80F0
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
ITT CANNON CA3100E36-7SBF80F0 Circular Connector, CA-B Series, MIL-DTL-5015 Series Equivalent, Wall Mount Receptacle, 47 Contacts
PDF
/
Inventory: 2557
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material NOT SPECIFIED
Contact Plating Silver
Mounting Type CABLE AND PANEL
Shell Material ALUMINUM ALLOY
Body Material Aluminium
Technical
Published 2016
Part Status Active
ECCN Code EAR99
Connector Type MIL SERIES CONNECTOR
Gender Receptacle
HTS Code 8536.69.40.20
Contact Finish - Mating NOT SPECIFIED
MIL Conformance YES
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Military Standard MIL-DTL-5015
Shell Finish CHROMATE PLATED
Number of Contacts 47
Empty Shell YES
Backshell Type SOLID
Contact Style Socket
Environmental Characteristics CORROSION RESISTANT
Shell Size 36
Termination Type CRIMP
Coupling Type BAYONET
Body Plating Cadmium
Compliance
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
