MCR10EZHJ680
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description
0805 (2012Metric) FIXED RESISTOR MCR 0.079Lx0.049W 2.00mmx1.25mm 0.125W 1/8W 68Ohm ±200ppm/C
PDF
/
Inventory: 8076
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Package / Case 0805 (2012 Metric)
Terminal Shape WRAPAROUND
Technical
Operating Temperature -55°C~155°C
Packaging Tape & Reel (TR)
Published 2002
Series MCR
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance ±5%
JESD-609 Code e3
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Temperature Coefficient ±200ppm/°C
Resistance 68Ohm
Composition Thick Film
Power (Watts) 0.125W 1/8W
Subcategory Fixed Resistors
Power Rating 125mW
Voltage - Rated DC 150V
Packing Method TR, PAPER, 7 INCH
Max Power Dissipation 125mW
Construction Chip
Resistor Type FIXED RESISTOR
Case Code (Metric) 2012
Case Code (Imperial) 0805
Working Voltage 150V
Dimensions
Height 609.6μm
Height Seated (Max) 0.026 0.65mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
