ERJ-MP4QF2M0U image
Favorite
ERJ-MP4QF2M0U image
Favorite
RoHS
RoHS RoHS compliant
Package 2512 (6432 Metric)
Category Resistors / Chip Resistor - Surface Mount
Description 2512 (6432Metric) 2512 ERJ 0.252Lx0.126W 6.40mmx3.20mm 3W 2mOhms ±75ppm/C
PDF
/
Inventory: 8427
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case 2512 (6432 Metric)
Supplier Device Package 2512

Technical

Operating Temperature -65°C~170°C
Packaging Tape & Reel (TR)
Published 2016
Series ERJ
Size / Dimension 0.252Lx0.126W 6.40mmx3.20mm
Tolerance ±1%
Feature Automotive AEC-Q200, Current Sense, Moisture Resistant
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Temperature Coefficient ±75ppm/°C
Resistance 2mOhms
Max Operating Temperature 170°C
Min Operating Temperature -65°C
Composition Metal Element
Power (Watts) 3W
Power Rating 3W
Max Power Dissipation 3W
Case Code (Metric) 6432
Case Code (Imperial) 2512

Dimensions

Height 889μm
Height Seated (Max) 0.035 0.89mm
Length 6.4008mm
Width 3.2004mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
