MFS1/4CC5601F
RoHS
/
Package Conformal
Category Resistors / Chip Resistor - Surface Mount
Description
Conformal FIXED RESISTOR Chip Resistor 250mW 5.6kOhm 50ppm/C 1%
PDF
/
Inventory: 9160
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Length 3.2mm
Diameter 1.7mm
Technical
Rated Temperature 70°C
Military Standard Not
Resistor Type FIXED RESISTOR
Construction Tubular
Packing Method BULK
Voltage - Rated DC 250V
Power Rating 250mW
Subcategory Fixed Resistors
Additional Feature SEMI PRECISION
Composition Metal Film
Min Operating Temperature -55°C
Max Operating Temperature 155°C
Terminal Finish Tin/Copper (Sn/Cu)
Resistance 5.6kOhm
Temperature Coefficient 50 ppm/°C
ECCN Code EAR99
Termination Axial
Number of Terminations 2
Pbfree Code yes
JESD-609 Code e2
Tolerance 1%
Published 2009
Physical
Number of Pins 2
Mounting Feature THROUGH HOLE MOUNT
Terminal Shape WIRE
Surface Mount NO
Package / Case Conformal
