112APC
RoHS
/
Package /
Category Connectors, Interconnects / Barrel - Audio Connectors
Description
Phone Connectors 2C ENCLOSED 1/4"
PDF
/
Inventory: 3271
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Diameter 6.35mm
Technical
Signal Lines Mono
Actual Diameter 0.250 (6.35mm)
Industry Recognized Mating Diameter 6.35mm (0.250, 1/4) - Headphone
Panel Hole Size 0.375 9.52mm
Body Color Silver, Black
Internal Switch(s) Single Switch
Includes 3 pcs - 1 Connector, 1 Nut, 1 Washer
Number of Positions/Contacts 2 Conductors, 3 Contacts
Thread Size 3/8-32
Current Rating 3A
Shielding Unshielded
Orientation Vertical
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.10
Voltage - Rated 48VDC
Gender Female
Color Black
Connector Type Phone Jack
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Feature Mounting Hardware, Thread Lock
Series Hi-D? 11*
Published 1998
Operating Temperature -20°C~65°C
Physical
Contact Material - Plating Tin
Body Material Brass
Housing Material Polyester, Glass Filled
Number of Pins 2
Mounting Type Panel Mount, Through Hole
Mount Panel, Through Hole
Contact Plating Nickel, Tin
