ETC1-1-13TR
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD
Category RF/IF and RFID / Balun
Description
BALUN 4.5MHZ-3GHZ 1:1 5SMD
PDF
/
Buying Options
Total Price: USD $1.26
Unit Price: USD $1.26248
≥1 USD $1.26248
≥10 USD $1.19102
≥100 USD $1.1236
≥500 USD $1.06
≥1000 USD $1
≥3000 USD $0.9434
Inventory: 30839
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 5-SMD
Number of Pins 5
Technical
Packaging Tape & Reel (TR)
Published 2009
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -55°C
Power Rating 250mW
Packing Method TR
Depth 3.81mm
Physical Dimension L3.81XB2.79XH2.79 (mm)
Max DC Current 30mA
Application MATCHING
Bandwidth 2.9955 GHz
Frequency Range 4.5MHz~3GHz
Operating Frequency-Max 3000000kHz
Transformer Type RF TRANSFORMER
Insertion Loss (Max) 3.5dB
Number of Secondary Winding 1
Number of Primary Winding 1
Turns Ratio (NpNs) 1:1
Cut-off Frequency-Max 3000MHz
Impedance - Unbalanced/Balanced 1:1
Dimensions
Height 2.95mm
Length 3.81mm
Width 3.81mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
