0760559608
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Impact 76055 ROHS3Compliant Vertical GENERAL PURPOSE Connector Header, Male Pins UL94V-0 -55C~85C 30V 24.8mm
PDF
/
Inventory: 1982
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Contact Material NOT SPECIFIED
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Technical
Operating Temperature -55°C~85°C
Packaging Tray
Series Impact 76055
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Connector Type Header, Male Pins
Number of Positions 240
Color Black
Number of Rows 15
Additional Feature IMPACT, POLARIZED
HTS Code 8536.69.40.40
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.053 1.35mm
Total Number of Contacts 240
Orientation Vertical
Depth 24.8mm
Number of Positions Loaded All
Contact Finish Gold
Mating Information MULTIPLE MATING PARTS AVAILABLE
UL Flammability Code 94V-0
Max Voltage Rating (AC) 30V
Connector Style Impact, Guide Right
Contact Layout, Typical 80 Differential Pairs
Number of Columns 16
Dimensions
Length 30.3mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
