0737826200
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Backplane Connectors - Specialized
Description
Board to Board & Mezzanine Connectors HDM BP Stkg Mod Clsd Clsd End ST3.5 72Ckt
PDF
/
Inventory: 8353
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 29.5μin 0.75μm
Length 27.6mm
Technical
Number of Columns 12
Connector Style HDM
Max Voltage Rating (AC) 100V
Contact Resistance 10mOhm
UL Flammability Code 94V-0
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish Gold
Current Rating 1A
Number of Positions Loaded All
Depth 15.6mm
Orientation Vertical
Total Number of Contacts 72
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 6
Color Black
Number of Positions 72
Connector Type Header, Male Pins
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Stackable
Series HDM (High Density Metric) 73782
Packaging Tube
Operating Temperature -55°C~105°C
Physical
Housing Material Polymer
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold, Lead, Tin
Contact Material Bronze
Supply Chain
Factory Lead Time 7 Weeks
