ECL15UT03-P
RoHS
RoHS compliant
RoHS compliantPackage 7-DIP Module
Category Power Supplies - Board Mount / AC DC Converters
Description
XP POWER ECL15UT03-PAC/DC PCB Mount Power Supply, Ultra Compact, Adjustable, Fixed, 5V, 2A, 15VDC, 150mA, -15V, 150mA
PDF
/
Buying Options
Total Price: USD $46
Unit Price: USD $46
≥1 USD $46
≥10 USD $43.39623
Inventory: 34
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case 7-DIP Module
Weight 0.088lb 39.92g
Manufacturer Package Identifier ECL15UT03-P
Technical
Operating Temperature -20°C~70°C With Derating
Published 2000
Series ECL (15W)
Size / Dimension 2.44Lx1.21W x 0.96 H 62.0mmx30.7mmx24.4mm
Feature OVP, SCP
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Open Frame
Applications ITE (Commercial)
Subcategory Power Supply Modules
Power Rating 15W
Max Power Dissipation 15W
Depth 62mm
Number of Outputs 3
Approval Agency CSA, cUL, EN, IEC, UL
Efficiency 81%
Output Voltage 5V
Max Output Current 2A
Max Supply Voltage 264V
Min Supply Voltage 85V
Current - Output (Max) 2A 150mA 150mA
Voltage - Input 85V~264VAC
Output Current 2A
Output Power 15W
Protections OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Voltage - Output 2 15V
Topology Buck-Boost
Min Input Voltage 85V
Max Input Voltage 264V
Current - Output 1 2A
Voltage - Output 3 -15V
Max Output Power 15W
Current - Output 2 150mA
Switching Frequency 70kHz
Line Regulation ±0.5%
Load Regulation ±1%
Min Input Voltage (AC) 85V
Max Input Voltage (AC) 264V
Current - Output 3 150mA
Dimensions
Height 24.892mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
